Vertical storage is adopted for storaging carton blanks, for which carton blanks can be added at any time without stopping the machine; It’s suitable for forming and sealing cartons of the same size. If carton size need to be changed, the operator should adjust the machine manually(finishing in 2-3minutes); It’s rationally designed so that the forming, folding and sealing process are accomplished imultaneously; All the parts are precise and durable,without causing any vibration in runing. Running steadily with long life; Light in weight, high performance and speed.
|
Model |
CES5050 |
|
Carton Size |
L200~450mm/W150~400mm/H100~350mm |
|
Table height |
Min.H600mm Max.H720mm |
|
Speed |
1-10 box/min |
|
Dimension |
L2000×W1900×H1450mm |
|
Power supply |
220V/380V 50/60HZ |
|
Air source |
＞500L/min、 0.4~0.8 MPa |
|
Tape |
W48mm-W60-75mm×L1000 |
|
Machine weight |
NW-400kg GW-550kg |
